ANEVS(F) Series Battery Simulator

ANEVS(F) Series Battery Simulator

    ANEVS(F) series battery simulators take bidirectional DC power supply with high precision and high dynamic response as the core, to simulate the external characteristics of battery based on the accurate modeling of various of types of batteries.

Product Introduction

ANEVS(F) series battery simulators take bidirectional DC power supply with high precision and high dynamic response as the core, to simulate the external characteristics of battery based on the accurate modeling of lithium manganese oxide, lithium cobalt oxide, lithium iron phosphate, lead acid, nickel metal hydride batteries. ANEVS series battery simulators are professional equipment specially designed and developed for new energy vehicle power test benches, high control accuracy and fast dynamic response, widely used in testing of motor controllers, motors, and new energy vehicle powertrain. The performance of the ANEVS series battery simulator is better than GB/T 18488 Drive motor system for electric vehicles - Specification and experimental conditions, and GB/T 29307-2012 The reliability test methods of drive motor system for electric vehicles.

ANEVS(F) series battery simulator adopts high-frequency PWM rectification and bidirectional DCDC conversion, FPGA digital control, seamless switching between forward and reverse, automatic bidirectional operation, energy feedback to the grid at full power; advanced digital control, ultra-high control accuracy, fast response, wide output voltage range; compared with conventional bidirectional power supply, it can achieve full range of high-precision output from 0V to full scale, up to 2000V, and the maximum power of a single machine can reach 1MW.

Abundant programming and testing functions, suitable for a variety of applications with different software; to simulate battery output characteristics and battery charge/discharge characteristics; providing 5 common types of battery models. Users can choose the type of battery, the number of battery cells in series, the number of cells in parallel and SOC parameters, so as to simulate the battery output characteristics and charge/discharge characteristics, including change to internal resistance during charging/discharging. In addition, custom battery model output is available.

Features

  • Grid feedback: both power supply and load characteristics, working as load for automatic energy feedback to the grid in addition to high-power DC power supply performance; energy saving, green and environment protection.
  • High-precision output: accuracy of output voltage/current: ±0.1% F.S.
  • Fast dynamic response: output voltage response time for 10%-90% sudden applied load and 90%-10% sudden shedding load: ≤5ms; +90%~-90% forward/reverse switching time: ≤10ms.
  • Mainstream high-frequency PWM rectification control, power factor: ≥0.99, THD and injected harmonic current meet the requirements of GB/T14549-93, high-quality energy feedback to the grid.
  • Accurate and perfect battery model to simulate a variety of battery characteristics. Users can choose the type of battery, the number of battery cells in series, the number of cells in parallel and SOC parameters.
  • Custom battery model output is available.
  • Advanced IGBT parallel technology to output peak power and peak current 1.3 times or more of the rating.
  • CC, CV, CP modes.
  • Multi protection: input over-voltage/under-voltage, lack phase, output over voltage, IGBT overheat, IGBT over current, over temperature protection, short circuit current-limiting protection.
  • Built-in EMI filter to filter the interference signal caused by the high-frequency switching process, to avoid interference to the motor controller when the battery simulator is running.
  • Communication and remote control: standard CAN, RS232/RS485 port and remote control software of the upper computer.
  • Large-screen LCD display, compatible with buttons and touch screen, suitable for operation under various harsh operating conditions.

Applications

  • Testing of electric vehicle motors and controllers
  • Testing of electric vehicle transmission system and powertrain system
  • Testing of special electric vehicle motors, controllers, electric vehicle transmission systems, and powertrain systems
  • Testing of new energy motor system
  • Testing of ship electric drive, electric drive system
  • Testing of charger and charging pile
  • Testing of battery pack charge/discharge
  • Testing of capacitor and super capacitor charge/discharge
  • Testing of energy storage system converter
  • Testing of UPS and EPS system
  • Testing off hybrid
  • Simulated battery to replace real battery-powered test applications
  • Power supply for high-power DC test


Output VI curve

Advanced IGBT parallel technology, high peak power and peak current output. Take ANEVS800-300(F) and ANEVS800-500(F) as examples:



Fast dynamic current response characteristics
